The ZC Lighting HB17 LED UFO High Bay Light is an energy-efficient, durable, and high-performance lighting solution tailored for industrial environments.
Featuring up to 200lm/W high lumen output, IP65 waterproof design, and premium heat dissipation, the HB17 delivers long-lasting reliability and brilliant illumination for large facilities.
Designed for performance and longevity — the HB17 combines industrial strength with smart control capabilities for modern warehouses and factories.
| Feature | Description |
|---|---|
| 💡 High Efficiency | Delivers up to 200lm/W, reducing energy use by over 70%. |
| 🧊 Excellent Heat Dissipation | Die-cast aluminum housing ensures stable thermal performance. |
| 🌧️ IP65 Waterproof Design | Works reliably in dusty or humid environments. |
| ⚡ 10KV Surge Protection | Prevents damage from voltage spikes. |
| 🕒 Long Lifespan | Up to 50,000 hours of maintenance-free operation. |
| 🧠 Smart Control Options | Compatible with 0–10V / DALI / Microwave sensor. |
| 🛠️ Flexible Mounting | Supports hook, chain, and bracket installation. |
| 🔋 Energy Efficient | Ideal replacement for 400–1000W metal halide lamps. |
| Parameter | Specification |
|---|---|
| Power Range | 100W / 150W/ 200W/ 240W |
| Luminous Efficacy | 140-200Lm/W |
| Luminous Flux | 14,000Lm – 20,000Lm/21,000Lm – 30,000Lm/28,000Lm – 40,000Lm/33,600Lm – 45,600Lm |
| Input Voltage | AC100-277V/AC220-240V |
| Power Factor | >0.95 |
| Beam Angles | 60°, 90°, 120° (3-in-1 Lens) |
| CCT | 3000K / 4000K / 5000K / 5700K / 6500K |
| CRI | 70, 80 |
| SDCM | 6 |
| THD | <15% (@480Vac/60Hz, 25℃, full load) |
| Percent Flicker | <1% |
| IP Rating | IP65 |
| IK Rating | IK08 |
| Housing Material | Die-cast Aluminum + PC Lens |
| Lifespan | 50,000 Hours |
| Operating Temp | -30°C ~ +45°C (-86°F ~ +113°F) |
| Mounting | Hook / Chain / Bracket |
| Control Options | 0–10V / DALI / Microwave Sensor |
| Certifications | CE / RoHS / ETL / DLC / SAA |
| Warranty | 5 Years |
| Feature | Description | |
|---|---|---|
| 🌧️ | IP65 Waterproof | Withstands dust, humidity, and outdoor conditions. |
| ⚡ | 10KV Surge Protection | Safeguards electronics from sudden voltage surges. |
| 💥 | IK08 /IK10 Impact Resistance | Built with durable housing for industrial safety. |
| 🌡️ | Superior Heat Dissipation | Maintains low junction temperature for longer LED life. |
| 🕒 | Long Lifespan Design | Up to 50,000 hours of consistent performance. |
💬 Reliable lighting even in the harshest environments – from manufacturing lines to warehouse ceilings.
The HB17 series integrates precision-engineered optical lenses that deliver:
Uniform, glare-free light distribution
High luminous uniformity with no dark zones
Beam options optimized for high ceilings
Compatibility with motion and daylight sensors
⚙️ Engineered for maximum performance and visual comfort.
ZC Lighting HB17 LED UFO High Bay Light is ideal for a wide range of professional applications:
🏢 Warehouses & Distribution Centers
🏭 Manufacturing Workshops
🚗 Automotive Service Garages
🧊 Cold Storage Facilities
🛒 Supermarkets & Retail Areas
🏋️ Gymnasiums & Sports Halls
🚧 Construction & Logistic Bases
💡 Perfect for areas requiring uniform, bright, and cost-effective illumination.
Nuestras luces cuentan con una carcasa aerodinámica hecha de aluminio de alta pureza, lo que garantiza una refrigeración eficiente y una vida útil prolongada.
Nuestro sistema de control inteligente ofrece monitoreo remoto y ajustes automáticos, mejorando la eficiencia de la gestión.
Nuestras luces utilizan LED de alta eficiencia para retrasar la pérdida de luz y mantener una iluminación óptima.
Elija entre varios niveles de potencia
Para satisfacer sus necesidades de iluminación.
Varios colores y materiales para adaptarse.
diferentes entornos y necesidades.
Sistemas de control inteligentes para una gestión eficiente
gestión remota.
Diversos métodos de instalación para adaptarse a diferentes necesidades ambientales.
Alta protección y diseño de enfriamiento efectivo para mayor durabilidad.
Marca y embalaje personalizados para mejorar su imagen.
Los productos están sujetos a múltiples certificaciones técnicas y pruebas como CE, BIS e ISO 9001 cada año según los requisitos del cliente, garantizando el cumplimiento de los estándares internacionales de seguridad, calidad y eficiencia.
Considere las patentes para cada tecnología para garantizar la protección legal y la exclusividad del mercado.
Los procesos de producción relevantes se han actualizado a estándares internacionales.
El 10% de las ganancias se invierte anualmente en la mejora continua de los productos.
