Name: LED Stadium Light FL10
Brand: ZCLEDS
Availability: InStock

Elija forma y tamaño: explore nuestras opciones de forma y tamaño y seleccione la que mejor se adapte a su diseño.

Confirmar pedido: Aprueba la maqueta y los detalles del pedido y comenzaremos la producción.

Producción rápida: El proceso de producción eficiente garantiza que su pedido se complete en poco tiempo.

Envío global: Apoyamos el envío global para garantizar que sus productos le lleguen rápidamente.

[{"id":46379377098990,"title":"400W","option1":"400W","option2":null,"option3":null,"sku":"","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"LED Stadium Light FL10 - 400W","public_title":"400W","options":["400W"],"price":0,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]},{"id":46379377131758,"title":"500W","option1":"500W","option2":null,"option3":null,"sku":"","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"LED Stadium Light FL10 - 500W","public_title":"500W","options":["500W"],"price":0,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]},{"id":46379377164526,"title":"600W","option1":"600W","option2":null,"option3":null,"sku":"","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"LED Stadium Light FL10 - 600W","public_title":"600W","options":["600W"],"price":0,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]},{"id":46379377197294,"title":"800W","option1":"800W","option2":null,"option3":null,"sku":"","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"LED Stadium Light FL10 - 800W","public_title":"800W","options":["800W"],"price":0,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]},{"id":46379377230062,"title":"1000W","option1":"1000W","option2":null,"option3":null,"sku":"","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"LED Stadium Light FL10 - 1000W","public_title":"1000W","options":["1000W"],"price":0,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]},{"id":46379377262830,"title":"1200W","option1":"1200W","option2":null,"option3":null,"sku":"","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"LED Stadium Light FL10 - 1200W","public_title":"1200W","options":["1200W"],"price":0,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]},{"id":46379377295598,"title":"1600W","option1":"1600W","option2":null,"option3":null,"sku":"","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"LED Stadium Light FL10 - 1600W","public_title":"1600W","options":["1600W"],"price":0,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]},{"id":46379377328366,"title":"2000W","option1":"2000W","option2":null,"option3":null,"sku":"","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"LED Stadium Light FL10 - 2000W","public_title":"2000W","options":["2000W"],"price":0,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[]}]

The ZC Lighting FL10 LED Stadium Light is a premium-grade lighting solution engineered for sports arenas, stadiums, and large outdoor fields.

Equipped with top-tier Lumileds or Osram chips and up to 180lm/W luminous efficacy, FL10 provides brilliant brightness, precision optics, and maximum durability under all weather conditions.

Key Features

Feature	Description
💡 Ultra High Efficiency up to 180lm/W	Delivers superior brightness with reduced power consumption.
🎯 Professional Optical Lenses	10°, 15°, 20°, and 30° beam angles for perfect light control.
🌧️ IP66 Waterproof & IK10 Impact Resistant	Designed for outdoor stadium and sports field environments.
🌡️ Excellent Heat Dissipation	Unique fin design ensures consistent thermal performance.
⚡ Surge Protection 10KV/20KV	Safeguards against power spikes and lightning surges.
🧠 Smart Control Options	Supports DALI / 0–10V dimming / DMX control for precise lighting effects.
🔋 Long Lifespan >50,000 Hours	Reliable performance for long-term operation.
🛠️ Modular Design	Easy maintenance and flexible wattage combinations.

📐Electrical & Optical

Parameter	Specification
Power	400W / 500W / 600W / 800W / 1000W / 1200W / 1600W/ 2000W
Luminous Efficiency	140–180 lm/W
Input Voltage	AC100–277V / 277-480V
Power Factor	≥0.95
Beam Angles	10° / 25° / 45° / 60°
CCT	3000K / 4000K / 5000K / 5700K/ 6500K
CRI	Ra ≥ 80 / Optional Ra ≥ 90 + TCLI 90＋
IP Rating	IP66
IK Rating	IK10
Housing Material	Die-cast Aluminum + Tempered Glass
Operating Temp	-30°C ~ +50°C
Control Options	DALI / DMX512 / 0–10V Dimming
Surge Protection	10KV / 20KV
Certifications	CE / RoHS / ENEC / ETL / DLC
Warranty	5 Years
Lifespan	50,000 Hours

🔒Protection & Reliability

	Feature	Description
🌧️	IP66 Waterproof	Perfect for outdoor environments exposed to rain and dust.
⚡	10KV/20KV Surge Protection	Ensures electrical safety and system stability.
💥	IK10 Impact Resistant	Resists mechanical shock and sports ball impacts.
🌡️	Thermal Control System	Prevents overheating and maintains LED efficiency.
🔋	50,000H Lifespan	Long-term durability for sports venues and arenas.

🧠 Designed to perform flawlessly under any weather or sports conditions.

🔑Product Comparison and Competitive Advantages

Feature	FL10	Traditional Metal Halide	Generic Flood Light
Efficiency	★★★★★	★★☆☆☆	★★★☆☆
Lifespan	50,000h	<15,000h	30,000h
Heat Dissipation	Excellent	Poor	Moderate
Maintenance	Low	High	Medium
Glare Control	Precise optics	Poor	Average
Weather Resistance	IP66	IP54	IP65

🔍 Optical Design & Performance

FL10 integrates precision-engineered lenses and anti-glare technology, offering:

Uniform and shadow-free illumination
UGR < 25 for athlete and spectator comfort
Multiple optical distributions for tailored projects
Optional DMX control for dynamic lighting effects

🎯 Precision optics = Professional lighting experience.

🏟️ Application Scenarios

ZC Lighting FL10 LED Stadium Lights are ideal for:

🏟️ Football / Soccer Stadiums
🏀 Basketball & Tennis Courts
🏁 Race Tracks & Outdoor Arenas
🏐 Multi-purpose Sports Fields
⛳ Golf Driving Ranges
🚧 High Mast Floodlighting Projects
⚓ Ports & Outdoor Industrial Yards

💡 From sports lighting to industrial high mast illumination, FL10 is your all-in-one solution.

DISEÑO DE ILUMINACIÓN PERSONALIZADA

Asegúrese de que su proyecto cumpla con el código local y cumpla con los niveles de iluminación requeridos con diseños personalizados creados por el equipo de diseño de ZC Lighting.

Organiza juegos y torneos de alto nivel

Cumpla con los requisitos de las ligas superiores con niveles de iluminación adecuados.

Más de 10 años de experiencia en iluminación LED

Casos exitosos de asociación de marca compartida y soluciones tecnológicamente avanzadas continuas

¿Estás luchando con estos problemas de iluminación típicos?

❓¿Se ha reducido la vida útil debido a una mala disipación del calor?

Nuestras luces cuentan con una carcasa aerodinámica hecha de aluminio de alta pureza, lo que garantiza una refrigeración eficiente y una vida útil prolongada.

❓¿Le preocupa que interfieran con otros equipos?

Nuestro sistema de control inteligente ofrece monitoreo remoto y ajustes automáticos, mejorando la eficiencia de la gestión.

❓¿Has notado una disminución de la luminosidad con el paso del tiempo?

Nuestras luces utilizan LED de alta eficiencia para retrasar la pérdida de luz y mantener una iluminación óptima.

¿Cómo puede ZC Lighting personalizar sus soluciones de iluminación LED?

Energía y CCT

Elija entre varios niveles de potencia

Para satisfacer sus necesidades de iluminación.

Opciones de diseño

Varios colores y materiales para adaptarse.

diferentes entornos y necesidades.

Control inteligente

Sistemas de control inteligentes para una gestión eficiente

gestión remota.

Montaje versátil

Diversos métodos de instalación para adaptarse a diferentes necesidades ambientales.

Refrigeración protectora

Alta protección y diseño de enfriamiento efectivo para mayor durabilidad.

Marca y embalaje

Marca y embalaje personalizados para mejorar su imagen.

Certificaciones

Los productos están sujetos a múltiples certificaciones técnicas y pruebas como CE, BIS e ISO 9001 cada año según los requisitos del cliente, garantizando el cumplimiento de los estándares internacionales de seguridad, calidad y eficiencia.

45 +

Patente certificada

Considere las patentes para cada tecnología para garantizar la protección legal y la exclusividad del mercado.

50 +

Equipos de producción

Los procesos de producción relevantes se han actualizado a estándares internacionales.

10%

Nuevos gastos de I+D

El 10% de las ganancias se invierte anualmente en la mejora continua de los productos.
